Q Series HD Portable Industrial Borescope
Q Series HD Portable Industrial Borescope
The Yateks Q Series HD Portable Industrial Borescope is a compact, high-performance remote visual inspection (RVI) solution designed for fast, accurate, and non-destructive inspections in demanding industrial environments. Featuring high-definition imaging, a lightweight portable design, and intuitive operation, the Q Series enables engineers and maintenance professionals to inspect inaccessible areas with exceptional clarity, helping reduce equipment downtime and maintenance costs.
Technical Advantages
- 5.5-inch OLED touchscreen with a wide viewing angle and realistic color reproduction.
- Clear display enables detection of subtle defects even in bright sunlight.
- High-definition megapixel camera with advanced digital image processing for ultra-clear images.
Applications
- Power Generation – Inspection of turbines, generators, and power equipment.
- Automotive Technology – Engine and internal component inspection.
- Transportation – Maintenance of rail, marine, and heavy vehicles.
- Process Industry – Inspection of pipelines, tanks, and machinery.
- Aviation – Aircraft engine and turbine component inspection.
Technical Specifications
Insertion Tube Specifications
| Specification | Details |
|---|---|
| Insertion Tube Material | Tungsten-Braided Insertion Tube |
| Camera Articulation | 0° to 180° |
| Bending Angle | 0° to 180° |
| Effective Pixels | 45K to Megapixels |
| Depth of Field | Refer to Model Number List |
| Angle of View | Refer to Model Number List |
| Front Probe | Replaceable probe with support for multiple probe options. |
Software Specifications
| Specification | Details |
|---|---|
| Operating System | Real-Time Multitasking Operating System |
| User Interface | Pop-Up Drive Operation with Menu Navigation |
| File Management | Supports Photo & Video Playback, Delete, and Format |
| Image Editing | Zoom, Playback, Editing, Graffiti, and File Renaming |
| Photo Format | BMP, PNG, JPG |
| Video Format | AVI, MP4 |
| Supported Languages | English, Chinese, Korean, German, Russian, Japanese |
| Color Settings | Adjustable Color Specifications |
| Exposure | Adjustable Exposure Time |
| Measurement | 2D Comparison Measurement |
| Software Update | Upgrade via SD Card Service Pack |
Operating Environment
| Specification | Details |
|---|---|
| Monitor Working Temperature | -20°C to 50°C |
| Probe Working Temperature | -20°C to 70°C |
| Relative Humidity | Up to 95% RH |
| Waterproof Rating | Probe: IP67 |
